Norco Optic C3 29" Bike

Name: Norco Optic C3 29" Bike
Brand: Norco
Price: 4599 GBP
Availability: InStock

Be the first to review this product

SKU

VAR-NO-0680415924

From £4,599.00 £3,832.50

Trade Only Item

Discipline: Trail
Wheelsize: 29"
Rear Travel: 125mm
Frame Material: Carbon Fibre

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Add to Wish List

Details

Fluid VLT Wordmark

Whether you’re ripping fast flowy singletrack, putting the power down on punchy climbs, or tearing the tires off in the corners, the Optic continues to push the boundaries of what’s possible on a short travel trail bike.

NEW TECHNOLOGY

With 140mm/125mm of travel, the Optic condenses years of technology from long travel bikes into a lightweight package that’s as comfortable tearing up climbs as it is tackling challenging descents.

The VPSHP suspension layout provides increased rearward axle path and an idler to manage pedal feedback, keeping Optic’s playful roots, while punching above its weight when the trails get rough.

GEOMETRY

Coming in five frame sizes (1,2,3,4,5) to support rider heights up to 6’5" (196cm), allows you to choose the frame size that best fits your body and riding preferences.

Rear centres and seat tube angles are varied by frame size to ensure consistent rider weight distribution, and short seat tubes with long dropper posts keep the saddle out of the way on technical descents.

FORCE SEPARATION

Optic’s High Pivot Horst Link suspension provides control of anti-rise, which is a fancy way of saying braking forces and suspension action operate pretty much independent of one another, so your suspension works its best on or off the brakes.

PRECISION KINEMATICS

Large volume air springs, precision leverage curves and custom shock tunes provide an ideal balance of bump sensitivity and the support you need to feel connected to the trail. 50mm shock stroke and reduced leverage accommodates heavier riders while still ensuring proper setup for lighter folks.

SIZE & STYLE

Fully-committed, aggressively playful performance featuring size-specific Rear- Centres & Seat Tube Angles across all 5 frame sizes, giving you the best chance to find the perfect fit for your size & style.

YOU DO YOU

Optic Carbon is available with dual 29” wheels and one 29”/27.5” MX wheel model so you can toe the line, or let your hair down. Plus, you can buy the Missing Links later if you get curious about how the other side rides.

CARBON FRAME

Full carbon fibre frame and stays are engineered to optimize strength, stiffness and light weight, ensuring you hit the line you want every time and intuitively navigate the toughest terrain.

RIDE ALIGNED™

Perfect fit, dialed handling and personalised setup in minutes.

The Ride Aligned™ Design System matches each Optic to the human who rides it with Rider-First geometry and suspension that’s precision tuned in minutes to you and terrain you ride with the Ride Aligned™ Bike Setup Guide.

SPECIFICATION

FRAME	Carbon Frame, 125mm Travel, UDH, Eagle Transmission
FORK	RockShox Pike Select, 140mm, 44mm offset
REAR SHOCK	RockShox Super Deluxe Select+, 185x50mm TR
HEADSET	FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 \| ZS56/40 )
GRIPS	Propalm, 130mm Length
HANDLE BAR	6061 Alloy, 800mm, 25mm Rise
STEM	Norco 40mm length, 35mm clamp
SEAT POST	TranzX YS105, 34.9mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5)
SADDLE	SDG Bel Air V3
FRONT BRAKE	Shimano Deore MT520 4-Piston, Metallic Pads
FRONT BRAKE ROTOR	Shimano RT-64, 180mm rotor, C-Lock
REAR BRAKE	Shimano Deore MT520 4-Piston, Metallic Pads
REAR BRAKE ROTOR	Shimano RT-64, 180mm rotor, C-Lock
BRAKE LEVERS	Shimano Deore MT520
SHIFTER REAR	Shimano Deore SL-M6100, 12sp
REAR DERAILLEUR	Shimano XT M8100, 12sp
CASSETTE	Shimano Deore CS-M6100-12, 10-51T, 12sp
CHAIN	Shimano Deore CN-M6100, 12sp
CRANKSET	Shimano Deore FC-MT512, 30T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5)
BOTTOM BRACKET	Shimano Sealed Bearing, BSA 73mm
FRONT HUb	Shimano HB-MT410, 15x110mm Boost, 32H, C-lock
REAR HUB	Shimano FH-MT510, 12x148 Boost, Micro Spline, 32H, C-lock
SPOKES/NIPPLES	Stainless steel
RIMS	WTB ST i30, 32H, F/R-29", 30mm ID
FRONT TYRE	Maxxis Minion DHF, 3C Max Terra EXO, 29x2.5", Folding
REAR TYRE	Maxxis Dissector, 3C Max Terra EXO, 29x2.4", Folding

Please note: Specifications are subject to change without notice.

GEOMETRY

All measurements are shown in millimetres.

		1	2	3	4	5
	WHEEL SIZE	29"
	RIDER HEIGHT (FT)	5'1-5'5"	5'4-5'8"	5'7-5'11"	5'10-6'2"	6'1-6'5"
	RIDER HEIGHT (CM)	155.0-165.0	162.5-172.5	170.0-180.0	178.0-188.0	185.5-195.5
	TRAVEL (MM FRONT / MM REAR)	140/125mm
	REACH	422.5	447.5	472.5	497.5	522.5
	STACK	608	617	626	635	644
HTA	HEAD TUBE ANGLE	65.0
OS	FORK OFFSET	44
ST	SEAT TUBE LENGTH	350	370	385	430	445
STA	EFFECTIVE SEAT TUBE ANGLE	76.50	76.75	77.00	77.25	77.50
RC	REAR CENTRE LENGTH	421	425	429	433	437
BB	BOTTOM BRACKET DROP	32/32
BBH	BOTTOM BRACKET HEIGHT	346
HTT	HORIZONTAL TOP TUBE	568	593	617	641	665
WB	WHEELBASE	1159	1193	1226	1259	1292
SOH	STANDOVER	675	677	678	707	705
HT	HEAD TUBE LENGTH	100	110	120	130	140
	TRAIL	128
	RECOMMENDED SEATPOST DROP	150	170	200	200	230
	MAXIMUM POST INSERTION	250	270	300	300	330
	STEM LENGTH	40
	CRANK LENGTH	170
	TYRE SIZE	2.35" - 2.6"
	WATER BOTTLE COMPATIBLE	1 x 620ml	1 x 750ml	1 x 750ml	1 x 750ml	1 x 750ml
