Norco Search A 700c Bike

Name: Norco Search A 700c Bike
Brand: Norco
Price: 1999 GBP
Availability: OutOfStock

Be the first to review this product

SKU

VAR-NO-0406015834

From £1,999.00 £1,665.83

Trade Only Item

Photos coming soon

Bike Specifications are subject to change without notice.

Specifications may not be exactly as shown in photo.

Discipline: Gravel
Wheelsize: 700c
Frame Material: Aluminium

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Add to Wish List

Details

Singletrack, dirt roads, city parks, even the most remote back country trails – are you roaming or racing? The updated Search Carbon is ready for your next gravel adventure with a modernised lightweight carbon frame featuring Norco's proprietary downtube storage for all your goodies and gear to get you there.

NEW TECHNOLOGY

Snacks, tools, layers and survival staples are vital for any adventure.

The lightweight carbon frame features proprietary downtube storage with a set of two storage bags perfect for all your emergency essentials, and a serious stash of gummy bears.

The frame is UDH-compatible and supports fitments for all the latest wide range 1x drivetrain technologies.

Geometry

Updated Modern Gravel Geo

The new Search is fast, light, and responsive on gravel, while staying stable at speed and confident through rough terrain.

FRAME

The Search C is available in 5 frame sizes, Featuring a lightweight rigid gravel frame, updated modern geometry, downtube storage and a maximum tyre clearance of 700x50c across all sizes.

SPECIFICATION

FRAME	Aluminium
FORK	Search XR Carbon, 51mm offset, 12x100 TA
HEADSET	Integrated Angular Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 \| IS52/40 )
GRIPS	Griptacular Shockproof Tape 3mm
HANDLE BAR	Norco Super Flare Aluminium, 16 Deg Flare, S1/2=40cm; S3=42cm; S4=44cm; S5=46cm
STEM	Norco SL Aluminium, 70mm length, 31.8mm Clamp
SEAT POST	Norco Aluminium, 12mm offset, 27.2mm ID, 350mm Length
SADDLE	Selle Royale SRX Gravel, 148mm
FRONT BRAKE	Shimano BR-RX400, Resin pads
FRONT BRAKE ROTOR	Shimano SM-RT54, 160mm, C-lock
REAR BRAKE	Shimano BR-RX400, Resin pads
REAR BRAKE ROTOR	Shimano SM-RT54, 160mm, C-lock
SHIFTER FRONT	Shimano GRX ST-RX610, 2x
SHIFTER REAR	Shimano GRX ST-RX610, 12sp
FRONT DERAILLEUR	Shimano GRX FD-RX820, Braze On, Down Swing, 2x
REAR DERAILLEUR	Shimano GRX RD-RX822, 12sp
CASSETTE	Shimano CS-HG710, 11-36T, 12sp
CHAIN	KMC X12, 12sp
CRANKSET	Shimano GRX FC-RX610, 46-30T, 2x12spd, BSA 24mm , S1/2/3/4=170; S5=172.5
BOTTOM BRACKET	Shimano SM-BBR60, Threaded, HOLLOWTECH II ,68/70 mm
RIMS	Alloy Tubeless Pinned, 23mm ID, 28H
FRONT HUB	Shimano HB-TC500, 12x100mm, Sealed Bearing, 28H, C-lock
REAR HUB	Shimano FH-TC500, 12x142mm, Sealed Bearing, Microspline, 28H, C-lock
FRONT TYRE	SCHWALBE G-ONE, 700X45C ALL ROUND PERF RACE GUARD
REAR TYRE	SCHWALBE G-ONE, 700X40C ALL ROUND PERF RACE GUARD

Please note: Specifications are subject to change without notice.

GEOMETRY

All measurements are shown in millimetres.

		Size 1	Size 2	Size 3	Size 4	Size 5
	WHEEL SIZE	700c
	REACH	385	400	415	430	445
	STACK	554	564	587	611	634
HTA	HEAD TUBE ANGLE	69.5
OS	FORK OFFSET	51
ST	SEAT TUBE LENGTH	440	475	510	545	580
STA	EFFECTIVE SEAT TUBE ANGLE	74.50	74.25	74	73.75	73.50
RC	REAR CENTRE LENGTH	425	425	427.5	430	430
BB	BOTTOM BRACKET DROP	75
BBH	BOTTOM BRACKET HEIGHT	285
HTT	HORIZONTAL TOP TUBE	539	559	583	608	633
WB	WHEELBASE	1037	1056	1082	1108	1132
SOH	STANDOVER	682	715	748	781	814
HT	HEAD TUBE LENGTH	100	110	135	160	185
	TRAIL	80
	MAXIMUM POST INSERTION	210	240	310	310	345
	STEM LENGTH	70
	CRANK LENGTH	165	170	170	172.5	172.5
	TYRE SIZE	40c - 50c
	WATER BOTTLE COMPATIBLE	3 x 750ml
