ARMEGA SP25
Norco Sight 160 C1 29/27.5" Bike

- TRADE ONLY ITEM
- Discipline: All-Mountain
- Wheelsize: 29"/27.5"
- Rear Travel: 160mm
- Frame Material: Carbon Fibre
The Sight 160 is next level - big travel, big spec, and ready for big mountain riding. Whether you're out racing an enduro or love going fast on technical trails, this is your bike to blow through the chunder. Inspired by the gnarliest trails in the backwoods of BC, built for riders living in areas where the terrain demands more out of the bike they ride.
TERRAIN-TAILORED SUSPENSION
Sight’s High Pivot Horst Link suspension platform features 160mm of net vertical travel in a rearward axle path to absorb high-speed, square-edge impacts to maintain momentum and control.

BALANCED PEDALING
Sight’s chainstay-mounted, dynamic idler positioning creates an All-Mountain-tuned anti-squat curve with minimal kickback under heavy impacts, and provides superior traction on technical climbs with efficient pedaling.
FORCE SEPARATION
Sight’s High Pivot Horst Link suspension provides control of anti-rise, which is a fancy way of saying braking forces and suspension action operate pretty much independent of one another, so your suspension works its best on or off the brakes.

GEOMETRY
With stabilised rear centres and seat tube angles varied by frame size to ensure consistent rider weight distribution and shorter seat tubes with long dropper posts keep the saddle out of the way on technical descents the Sight is known for, the Sight 160 features a slacker headtube angle and a slightly taller bottom bracket than our standard Sight geometry to accommodate all the G's you push and obstacles you roll.

SIZE & STYLE
Sight’s All-Mountain manners define Norco Ride Performance. With size-specific Rear- Centres & Seat Tube Angles unique to all 5 frame sizes, you’re sure to find the perfect fit for your size & style.
SUSPENSION
Bigger, steeper, better, badder - we've taken the confidence-inspiring stability of a Sight and made it more. Supported up front with a 170mm fork and in the rear with a longer 65mm stroke shock for 160mm; giving the Sight all you need for attacking tech and rougher, BC-inspired trails.

CARBON FRAME
Full carbon fibre frame and stays are engineered to optimise strength, stiffness and light weight, ensuring you hit the line you want every time and intuitively navigate the toughest terrain.

RIDE ALIGNED™
Perfect fit, dialed handling and personalised setup in minutes.
The Ride Aligned™ Design System matches each Sight to the human who rides it with Rider-First geometry and suspension that’s precision tuned in minutes to you and terrain you ride with the Ride Aligned™ Bike Setup Guide.
SPECIFICATION
FRAME | Carbon Frame, 160mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
FORK | Fox 38 Factory Float, Grip X2, HSC / LSC / LSR, 170mm, 44mm Offest,Fender Included |
REAR SHOCK | Fox Factory DHX2, 205x65mm TR,HSC/LSC, HSR/LSR 2 pos-Adj, Sprindex Spring |
HEADSET | FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 ) |
GRIPS | Ergon GE1, Slim (S1, S2) Standard (S3,S4,S5) |
HANDLE BAR | OneUp Aluminum, 800mm , 35mm rise |
STEM | OneUp 42mm Length , 35mm Clamp |
SEAT POST | OneUp V3 w/ OneUp 1x lever, 34.9mm, 150mm (S1) -180mm (S2) -210mm (S3,S4) -240mm (S5) |
SADDLE | SDG Bel Air 3 |
FRONT BRAKE | SRAM Maven Silver, Sintered Pads |
FRONT BRAKE ROTOR | SRAM HS2, 200mm, 2mm thickness, 6 bolt |
REAR BRAKE | SRAM Maven Silver, Sintered Pads |
REAR BRAKE ROTOR | SRAM HS2 180mm, 2mm thickness, 6 bolt |
BRAKE LEVERS | SRAM Maven Silver |
SHIFTER REAR | SRAM Pod Ultimate Controller, MMX Bridge |
REAR DERAILLEUR | SRAM GX Eagle AXS T-Type, 12sp |
CASSETTE | SRAM 1275 Eagle T-Type, 10-52T, 12sp |
CHAIN | SRAM GX Eagle T-Type, 12spd |
CRANKSET | Sram GX Eagle, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5) |
BOTTOM BRACKET | SRAM DUB, BSA 73mm, MTB WIDE |
CHAIN GUIDE | Norco idler guide cover and lower guard |
FRONT HUB SKEWER | DT Swiss 350, 15x110 Boost, 32H, 6-bolt |
REAR HUB | DT Swiss 350, 12x148 Boost, XD, 32H, 6-bolt |
SPOKES/NIPPLES | Sapim Race butted 2.0/1.8/2.0, 14G, stainless steel |
RIMS | Stan’s Flow S2, 32H, F- 29", R-27,5", 30mm ID |
FRONT TYRE | Maxxis Assegai, 3C MaxxGrip EXO+, 29x2.5", Folding |
REAR TYRE | Maxxis Minion DHR II, 3C Maxx Terra DD, 27.5x2.4", Folding |
Please note: Specifications are subject to change without notice.
GEOMETRY
All measurements are shown in millimetres.
1 | 2 | 3 | 4 | 5 | ||
WHEEL SIZE | 29"/27.5" | |||||
RIDER HEIGHT (FT) | 5'1-5'5" | 5'4-5'8" | 5'7-5'11" | 5'10-6'2" | 6'1-6'5" | |
RIDER HEIGHT (CM) | 155.0-165.0 | 162.5-172.5 | 170.0-180.0 | 178.0-188.0 | 185.5-195.5 | |
TRAVEL (MM FRONT / MM REAR) | 170/160mm | |||||
REACH | 416 | 441 | 466 | 491 | 516 | |
STACK | 618 | 627 | 636 | 645 | 654 | |
HTA | HEAD TUBE ANGLE | 63.5 | ||||
OS | FORK OFFSET | 44 | ||||
ST | SEAT TUBE LENGTH | 350 | 370 | 385 | 430 | 445 |
STA | EFFECTIVE SEAT TUBE ANGLE | 76.3 | 76.5 | 77 | 77.3 | 77.5 |
RC | REAR CENTRE LENGTH | 420 | 424 | 428 | 432 | 436 |
BB | BOTTOM BRACKET DROP | 20.5/0 | ||||
BBH | BOTTOM BRACKET HEIGHT | 357.5 | ||||
HTT | HORIZONTAL TOP TUBE | 567 | 591 | 615 | 639 | 663 |
WB | WHEELBASE | 1187 | 1220 | 1253 | 1287 | 1320 |
SOH | STANDOVER | 678 | 684 | 690 | 713 | 725 |
HT | HEAD TUBE LENGTH | 105 | 115 | 125 | 135 | 145 |
TRAIL | 135 | |||||
RECOMMENDED SEATPOST DROP | 150 | 170 | 200 | 200 | 230 | |
MAXIMUM POST INSERTION | 250 | 270 | 300 | 300 | 330 | |
STEM LENGTH | 40 | |||||
CRANK LENGTH | 170 | |||||
TYRE SIZE | 2.35" - 2.6" | |||||
WATER BOTTLE COMPATIBLE | 1 x 750ml |
Brand | Norco |
---|
