Norco Sight A1 29" Bike

Name: Norco Sight A1 29" Bike
Brand: Norco
Price: 5999 GBP
Availability: InStock

Be the first to review this product

SKU

VAR-NO-0623014934

From £5,999.00 £4,999.17

Trade Only Item

Discipline: All-Mountain
Wheelsize: 29"
Rear Travel: 150mm
Frame Material: Aluminium

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Add to Wish List

Details

The Sight is up for whatever ride you can conjure and will deliver the goods reliably and without fanfare. But don’t mistake that for not being up for a little mayhem. Norco’s legendary 150mm/160mm All-Mountain machine is the wingman you’ve always wished for – engineered with the self-confidence it takes to shine the spotlight directly on you, giving you the time of your life on every ride.

TERRAIN-TAILORED SUSPENSION

Sight’s High Pivot Horst Link suspension platform features 150mm of net vertical travel in a rearward axle path to absorb high-speed, square-edge impacts to maintain momentum and control.

BALANCED PEDALING

Sight’s chainstay-mounted, dynamic idler positioning creates an All-Mountain-tuned anti-squat curve with minimal kickback under heavy impacts, and provides superior traction on technical climbs with efficient pedaling.

FORCE SEPARATION

Sight’s High Pivot Horst Link suspension provides control of anti-rise, which is a fancy way of saying braking forces and suspension action operate pretty much independent of one another, so your suspension works its best on or off the brakes.

PRECISION KINEMATICS

Large volume air springs, precision leverage curves and custom shock tunes provide an ideal balance of bump sensitivity and the support you need to feel connected to the trail. 60mm shock stroke and reduced leverage accommodates heavier riders while still ensuring proper setup for lighter folks.

SIZE & STYLE

Sight’s All-Mountain manners define Norco Ride Performance. With size-specific Rear- Centres & Seat Tube Angles unique to all 5 frame sizes, you’re sure to find the perfect fit for your size & style.

YOU DO YOU

Sight is available with dual 29” wheels and 29”/27.5” MX wheel models so you can toe the line, or let your hair down. Plus, you can buy the Missing Links later if you get curious about how the other side rides.

ALUMINIUM FRAME

Smooth welded, hydroformed aluminium frame looks like a million bucks, but gives you the strength, reliability and performance you need to focus on the trail in front of you.

RIDE ALIGNED™

Perfect fit, dialed handling and personalised setup in minutes.

The Ride Aligned™ Design System matches each Sight to the human who rides it with Rider-First geometry and suspension that’s precision tuned in minutes to you and terrain you ride with the Ride Aligned™ Bike Setup Guide.

SPECIFICATION

FRAME	Sight Aluminum, High Pivot Horst Suspension, 150mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
FORK	RockShox Lyrik Ultimate, Charger 3, 160mm, 44mm offset, Fender Included
REAR SHOCK	RockShox Super Deluxe Ultimate Coil, 205x60mm
HEADSET	FSA #57 E, Sealed Bearing
GRIPS	WTB Wavelength Lock-On
HANDLE BAR	6061 Alloy, 800mm, 25mm Rise
STEM	CNC Alloy 40mm Length, 35mm Clamp
SEAT POST	TranzX YS108 Dropper, 34.9mm, 150mm (1), 170mm (2), 200 (3, 4), 230mm (5)
SADDLE	SDG Bel Air V3
FRONT BRAKE	SRAM Code Stealth Bronze, 4-Piston, Sintered Pads
FRONT BRAKE ROTOR	SRAM Centerline 200mm
REAR BRAKE	SRAM Code Stealth Bronze, 4-Piston, Sintered Pads
REAR BRAKE ROTOR	SRAM Centerline 180mm
SHIFTER REAR	SRAM Pod Ultimate Controller
REAR DERAILLEUR	SRAM GX Eagle AXS T-Type
CASSETTE	SRAM CS 1275 Eagle T-Type 10-52T
CHAIN	SRAM GX Eagle T-Type
CRANKSET	SRAM GX Eagle T-Type, 30T (29"), 32T (29'/27.5"), 170mm
BOTTOM BRACKET	SRAM DUB BSA Threaded
CHAIN GUIDE	Norco Idler Guide and Lower Guide
FRONT HUB	Race Face Vault, 15x110mm Boost, 6-Bolt
REAR HUB	Race Face Vault 12x148mm Boost, XD, 6-Bolt
SPOKES/NIPPLES	DT Competition Butted Black Stainless
RIMS	Stan's Flow S2, Black 32H, 29"/29" or 29"/27.5"
FRONT TYRE	Maxxis Minion DHF 2.5', 3C, MaxxTerra / EXO+ / TR, Folding
REAR TYRE	Maxxis Minion DHR II 2.4" WT, 3C, MaxxTerra / EXO+ / TR, Folding
SEALANT	Stan's Sealant - 200ml
VALVES	Universal 35mm Presta Valve Stem

Please note: Specifications are subject to change without notice.

GEOMETRY

All measurements are shown in millimetres.

		1	2	3	4	5
	WHEEL SIZE	29"
	RIDER HEIGHT (FT)	5'1-5'5"	5'4-5'8"	5'7-5'11"	5'10-6'2"	6'1-6'5"
	RIDER HEIGHT (CM)	155.0-165.0	162.5-172.5	170.0-180.0	178.0-188.0	185.5-195.5
	TRAVEL (MM FRONT / MM REAR)	160/150mm
	REACH	422.5	447.5	472.5	497.5	522.5
	STACK	618	627	636	645	654
HTA	HEAD TUBE ANGLE	64.0
OS	FORK OFFSET	44
ST	SEAT TUBE LENGTH	350	370	385	430	445
STA	EFFECTIVE SEAT TUBE ANGLE	77.00	77.25	77.50	77.75	78.00
RC	REAR CENTRE LENGTH	426	430	434	438	442
BB	BOTTOM BRACKET DROP	25/25
BBH	BOTTOM BRACKET HEIGHT	353
HTT	HORIZONTAL TOP TUBE	565	589	613	637	661
WB	WHEELBASE	1186	1219	1253	1286	1319
SOH	STANDOVER	666	680	689	710	720
HT	HEAD TUBE LENGTH	105	115	125	135	145
	TRAIL	135
	RECOMMENDED SEATPOST DROP	150	170	200	200	230
	MAXIMUM POST INSERTION	250	270	300	300	330
	STEM LENGTH	40
	CRANK LENGTH	170
	TYRE SIZE	2.35" - 2.6"
	WATER BOTTLE COMPATIBLE	1 x 750ml
