Yeti Cycles SB160 T-Series T3 X0 29" Bike

Name: Yeti Cycles SB160 T-Series T3 X0 29" Bike
Brand: Yeti Cycles
Price: 9499 GBP
Availability: OutOfStock

Be the first to review this product

SKU

VAR-YCB24160TSMPCBX2TE38700

Trade Only Item

Email me when back in stock

TRADE ONLY ITEM
Discipline: Enduro
Material: Carbon Fibre
Rear Travel: 160mm / Fork Travel: 170mm

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Add to Wish List

Details

SB160

Upholding a time-tested, race-bred ethos that says nothing should hold a rider back from the sheer joy of untethered speed. Built off one of the most winning race platform in EWS history, the sb160 is pure race machinery. Honed for more. Be fastest.

160MM

FRAME TRAVEL

170MM

FORK TRAVEL

17%

LEVERAGE RATE

29"

WHEEL SIZE

64°

HEAD TUBE ANGLE

77.5°

EFF. SEAT ANGLE

HIGHLIGHTS

Fox Factory 38 & Fox Float X2 Shock
Fox Transfer dropper post
DT Swiss EX Wheels
4 piston brakes
ODI Elite Pro grips
220 front and 200 rear rotors for max stopping power
Maxxis Assegai 2.5 & Minion DHR 2.4 EXO+ casing
Downhill tested and used by the Yeti Fox Factory team

FRAME HIGHLIGHTS

NEW Switch Infinity assembly on T-Series
NEW Threaded bottom bracket
NEW High-clearance downtube
NEW Dual-density downtube protection
Universal Derailleur Hanger (UDH)
Secure, fully enclosed internal cable management
Compatible with long dropper posts
100% standard sealed Enduro Max bearings
Floating collet axle pivot design
Compact-wishbone shock extender
Downhill tested
Yeti/Fox Factory team approved
Boost spacing
Sizes S-XXL

FROM LEGACY TO DYNASTY

The Yeti/Fox Factory Team won 51 EWS stages, 12 EWS races, and 1 national series championships aboard the SB150. The SB160 builds momentum on this legacy of excellence. Honed. Refined. Even effing faster.

SIZE GUIDE

SMALL	5'1" - 5'7"
MEDIUM		5'5" - 5'11"
LARGE			5'10" - 6'3"
X-LARGE				6'1" - 6'7"
XX-LARGE					6'5" - 6'11"

SPECIFICATION

TURQ Series carbon fibre frame, Switch Infinity suspension technology, threaded bottom bracket, fully enclosed internal cable routing,
148mm x 12mm BOOST dropouts, sealed Enduro Max pivot bearings, integrated derailleur hanger, and axle.

FORK	FOX FACTORY 38 GRIP 2/170MM
SHOCK	FOX FACTORY FLOAT X2
TYRE (F)	MAXXIS ASSEGAI 2.5 EXO+
TYRE (R)	MAXXIS MINION DHR II 2.4 EXO+
ROTOR (F)	SRAM CENTERLINE 220
ROTOR (R)	SRAM CENTERLINE 200
HEADSET	CANE CREEK 40 INTEGRATED
WHEELSET	RACEFACE ARC OFFSET 30MM/DT SWISS 350
BB	SRAM DUB BSA 73
GRIPS	ODI ELITE PRO
BAR	YETI CARBON 35X800MM
STEM	BURGTEC ENDURO MK3 35X50MM
CRANK	SRAM X0 EAGLE TRANSMISSION 30T 170MM
BASH GUARD	ONEUP BASH GUIDE
SADDLE	SILVERADO CUSTOM
BRAKES	SRAM CODE RSC
DERAILLEUR	SRAM X0 EAGLE AXS TRANSMISSION
CASSETTE	SRAM X0 EAGLE TRANSMISSION 10-52
CHAIN	SRAM X0 EAGLE TRANSMISSION FLATTOP
SHIFTER	SRAM AXS POD CONTROLLER
SEATPOST	FOX TRANSFER 31.6MM / 175MM

Please note: Specifications are subject to change without notice.

GEOMETRY

All measurements are shown in millimetres.

		SM	MD	LG	XL	XXL
A	SEAT TUBE LENGTH	365	400	440	470	485
B	EFF. TOP TUBE LENGTH	571	602	624	651	670
C	HEAD TUBE ANGLE	64	64	64	64	64
D	EFF. SEATTUBE ANGLE	77.5	77.5	77.5	77.5	77.5
E	ACTUAL SEATTUBE ANGLE	72.1	72.6	72.7	73.1	73.6
F	CHAINSTAY LENGTH	437	439	441	443	445
G	WHEELBASE	1211	1246	1270	1302	1329
H	ESTIMATED BB HEIGHT	353	353	353	353	353
I	STANDOVER	735	744	750	756	757
J	HEADTUBE LENGTH	95	101	107	118	140
K	FORK (AXLE TO CROWN)	588	588	588	588	588
L	FORK (OFFSET)	44	44	44	44	44
M	STACK	615	620	625	635	655
N	REACH	435	465	485	510	525
O	FRONT CENTER	774	807	829	859	884
P	VERTICAL FORK TRAVEL	153	153	153	153	153
